Faretec

NSN: 6515-01-706-4198

The CT-7 Leg Traction Splint is a carbon fiber leg traction device designed to provide femur traction in a field environment. The CT-7 is designed to eliminate cords, pulleys, redundant leg straps and does not extend beyond the patient's foot.

• All adjustments are done at the patient's ankle allowing clear view of patient limb length
• ACME Screw Traction Technology is precise, strong and accurate
• Treaded Rod Traction System allows for increases in traction in small increments
• Ability to apply 10 - 30 pounds of traction in approximately 30 seconds
• Does not extend beyond patient's foot
• Features a padded ischial strap and a one piece slip resistant ankle hitch
• Light weight (1.5 Lbs)

The CT-6 is a Leg Traction Splint designed for Pre Hospital Care and Patient transport, specifically in combat scenarios. It is primarily used on patients with mid-line femur fractures. The CT-6 helps relieve patient pain and prevents further damage to surrounding muscle and tissue while reducing the risk of death caused from severed arteries. The CT-6 is made of carbon tubing which snaps together via an internal bungee. A Cobra buckle secures the Ischial strap to the upper leg and groin. These buckles prevent accidental releases and are commonly used by US military forces. Traction is achieved with a 4 to1 purchase system using a small line to apply tension. This method results in a very precise and delicate form or traction that is also powerful enough to be effective on extra large adults. The CT-6 is extremely compact, light and strong.

• Light: Unit weighs 1.1 lbs (500 grams)
• Compact: Unit fits in small synch bag, 11 x 4 x 3in.
• Includes Molle compatible bag, labeled.
• Strong: Carbon Fiber poles and injection molded plastics.
• Effective: Four to one pulley system for efficient, easily adjustable traction.
• One unit fits both Adult and Pediatric patients.
• NSN 6515 01 521 5730
